Joining of furniture materials.

Perfect for the furniture industry, ultrasonic welding is suitable where rapid process times, coupled with good process reliability are required or if no other fillers or solvents are to be used. Ultrasonic welding process is an industrial technique using high-frequency ultrasonic acoustic vibrations under pressure to create a weld of two materials. Used for plastics and joining different materials together.

High-precision titanium or hardened steel sonotrode — Made in Germany
Additional welding modes like baste welding, spot weldingor “cut & seal” selectable
Anvil wheel from 25 to 45 mm diameter
Anvil wheel with adaptable puller function
Welding of tight radiuses due to an anvil diameter of 25 mm
Modular design (joint design for welding and sewing machines, for increased flexibility)
No use of compressed air
Welding with continuous or dynamic speed
Digital welding generator with 500 or 1000 Watt (optional)
Stepping motors for: Anvil wheel, sonotrode (separately controlled), welding gap and welding pressure
All machine parameters are programmable and storable
Simplified & intuitive program concept
Setup assistant
User identification with USB dongle possible
Free selectable access permission
Snap-in control panel
Network port for central administration of the machines (optional)
