Class: 1947BX6

Border Boxing

  • Operator friendly
  • Cord width size is quickly adjusted with a release pin
  • Left folder is fixed, only need to move the right folder, one needle and one looper thread
  • Folders easily slide out on a drawer type rail system to allow access to sewing components
  • Folder assembly is easily removed for sewing head maintenance, timing, etc
  • Independent stepper driven puller allows for push button increases or decreases in material stretch
  • Optional photocell controlled cutter is integral to the sewing unit and easily adjustable
  • Efka servo motor drive system
Max sewing speed (rpm) 2400
Factory preset speed (rpm) 2000
Max stitch length (spi) 6-7
Max needle distance (inch) 6
Needle system 62 x 57
Needle size 18/100
Weight of material MEDIUM
Max presser footlift (inch) 3-8
Voltage (v/ph/hz) 220V 1PH 60HZ
Current (amps) 5
Motor type EFKA DC
Air pressure (psi) 80
Air consumption (cfm) 1
Shipping weight (lbs) 980
Shipping dimensions (w/l/h, inch) 60 x 48 x 55
