Images may include options

Class: 1393ES

Combination Panel Cutting/Border Slitter/Rewinder

Auto-cutting of mattress panels and mattress borders. Use with quilting machine or separately.



  • Controlled by touch screen and Serial Bus Control operation
  • The size of panels and the total yards of borders can be preset
  • Precision cutting with touch screen programmable edge trim blades
  • Equipped with auto sharpening for all blades
  • Quiet reliable performance
Max cutting thickness (inch) 1 1/2″ (Compressed)
Min cutting thickness (inch) 1/4″
Max cutting width (inch) 102
Min cutting width (inch) 47 3/4
Max length (inch) 84
Min length (inch) 28 1/2
Voltage (v/ph/hz) 220V 3PH 50/60HZ
Current (amps) 20
Air pressure (psi) 80
Shipping weight (lbs) 5200
Shipping dimensions (w/l/h, inch) 144 x 65 x 78
Footprint

45 ft/min Output speed

Serial Bus

11393TC – Tensioning cart assembly
1393RC – Roller cart
1389873 – Additional blade holder
1393ES Panel Cutter, Border Slitter, Rewinder
1393EPCA Panel Cutting Only
1393EBSA Border Slitting Only
1393EBSW Border Slitting with Winder

This machine is mainly used for auto-cutting of mattress panels and mattress borders. It can be used together with the quilting machine or separately.
