Images may include options

1333

Class: 1333

Automatic Border and Foundation Closer

This stand-alone workstation may be moved to any department as needed.



  • Auto start/stop sewing operation
  • Heavy-duty lockstitch sewing head
  • Lockstitch ensures no stitch ravel at tape edge operation
  • Tractor style top feed swings up for easy threading and maintenance
  • Auto needle positioning, footlift and thread trimmer
  • Stand up sewing module
  • Close borders up to 18″ wide without adjustments
Max sewing speed (rpm) 5000
Factory preset speed (rpm) 1800
Max stitch length (spi) 6
Needle system SNDLX1140
Needle size 22/140
Weight of material LIGHT / MEDIUM / HEAVY
Max presser footlift (inch) 1/2
Voltage (v/ph/hz) 220V 1PH 60HZ
Current (amps) 5
Motor type DC
Air pressure (psi) 80
Air consumption (cfm) 1
Shipping weight (lbs) 700
Shipping dimensions (w/l/h, inch) 55 x 60 x 48
Footprint

240 Pieces per hour

Single Needle 301 Lockstitch Horizontal Hook, Transversal, Large Bottom Feed, Top Belt Feed Automatic Presser Footlift

1278-1095 Accessory Kit (Sew light, blow hose with a nozzle)

Operator loads border into clamp and activates auto cycle. Border is transferred to sewing head, machine backtacks beginning, end of border and closes border with a lockstitch which will not ravel.

• 11333 – Automatic Border & Foundation Closer
Workstation with modify Mitsubishi LS2-1380 Sewing
Head
• 11333A – Automatic Border & Foundation Closer
Workstation with modify Juki DNU-1541-7 Sewing Head
• 11333S – Automatic Border & Foundation Closer
Workstation with modify Pegasus EXT-3216 Sewing
Head
